Dichroic LED GU10 6W | SMD2835 SAMSUNG 145Lm/W |GLASS 38º

Reference: GU10ND6W-NW-90511

Led bulb GU10 6W SAMSUNG with glass body. Savings of up to 80% by replacing traditional halogens, offering a high quality and wide beam of light. It has 3 years warranty. It is a very good alternative with extensive decoration possibilities and great energy savings. Professional use.

6w
220-240V
83
660
38º
110Lm/W
IP20
25000
Ø50x54mm

Brightness calculation

1.Technical characteristics of the luminaire:

Indicate the technical characteristics of the LED projector or luminaire you wish to install:

Lumens (Lm): Luminous flux of the luminaire to be installed.

Angle (º): Angle of the luminaire to be installed.

Height (m): Total height in meters of the space (room) (axis "z").

2.Calculation of the individual capacity of the chosen luminaire:

Calculation of the luminous power and luminance of the LED luminaire defined in point 1.

Illuminated radius:

Total illuminated covered area:

3.Theoretical result:

Result of the luminous power and luminance.

Luminous Intensity (Candela - cd)

Surface illumination (lx)

Fast and secure delivery

Download technical datasheet

We offer professional prices for LED lighting

€1.83

No tax

Color temperature: Natural White - 4000K

Warm White - 2700K
Natural White - 4000K
5700K - Cold White

Download PDF

Description
Product Details

LED Bulb 6W 38°- SAMSUNG GU10 GLASS

Our SAMSUNG 6W GU10 LED Bulb is of high quality and specially designed for professional intensive use. The material with which it is made is Glass. It offers a high quality 38º beam of light. It has a range of 98 Lumens/Watt. It has a high CRI that allows a faithful reproduction of colors.

Its installation is simple. The old bulb is removed and the new lamp with a GU10 socket with direct connection to the mains is placed. Ideal for lighting corridors, closets, bathrooms, kitchens, shop windows, ceiling lights.

At FactorLED we ensure that our products have a QUALITY guarantee and offer all the necessary elements for DISTRIBUTION, IMPORT or WHOLESALE, including the technical sheet of each LED product.

Applications of the LED Bulb 6W 38°- SAMSUNG GU10 GLASS

Bathrooms
Closets
Bedrooms
Showcases
Showcases
Hallways
Stores
Commercial premises

Enjoy now this product with 5 Years Guarantee in our FactorLED online shop.

Reference GU10ND6W-NW-90511

Data sheet

REFERENCE: GU10-ND6W
Rated Power: 6w
Nominal Voltage: 220-240V
Colour: 2700K - 4000K - 5700K
CRI - Chromatic Rendiment Index: 83
Construction Material: Aluminiun+PC
Luminosity-Lm: 660
Number & Type of LEDs: SMD 2835 CHIP SAMSUNG
Beam Angle (º): 38º
Luminous diodo LED (Lm/W): 145 Lm/W
Luminous Efficiency (Lm/W): 110Lm/W
Base: GU10
Certifications: CE, CMIM, RoHS
IP: IP20
Diode Life Expectancy (H): 25000
Dimensions (mm): Ø50x54mm
Frequency (Hz): 50/60Hz
Temperature Range (ºC): +40ºC ~ -20ºC
On/Off Cycles: 100.000
Starting Time (s): 0,2s
Glare Rating (UGR): 21
Energy Rating (2021-UE-2019/2015): A+
Energy Rating (2023 - UE-2019/2015): F
Warranty Years: 3
